Product Summary
The MAX14550EETB is a highly integrated automotive analog-sensor signal processor for resistive element sensors. It provides amplification, calibration, and temperature compensation that enable an overall performance approaching the inherent repeatability of the sensor.
Parametrics
Absolute maximum ratings: (1)Supply Voltage:-0.3V to +6V; (2)VDD1-VDD2:-0.3V to +0.6V; (3)All Other Pins:(VSS - 0.3V) to (VDD_ + 0.3V); (4)Short-Circuit Duration:Continuous; (5)Continuous Power Dissipation (TA = +70℃):640mW; (6)storage temperature range:-65℃ to +150℃; (7)lead temperature (soldering,10s):+300℃.
Features
Features: (1)Provides Amplification, Calibration, and Temperature Compensation; (2)Selectable Output Clipping Limits; (3)Accommodates Sensor Output Sensitivities from 5mV/V to 40mV/V; (4)Single-Pin Digital Programming; (5)No External Trim Components Required; (6)16-Bit Offset and Span Calibration Resolution; (7)Fully Analog Signal Path; (8)PRT Bridge Can Be Used for Temperature-Correction Input; (9)On-Chip Lookup Table Supports Multipoint Calibration Temperature Correction; (10)Fast 3.2kHz Frequency Response; (11)On-Chip Uncommitted Op Amp; (12)Secure-Lock Prevents Data.
